| Make | Model | Year Range | Description | Position | Drive Wheel | Veh. Qty. |
|---|---|---|---|---|---|---|
| Buick | Roadmaster | 1992-1996 | Shock Absorber | Front | 2 | |
| Cadillac | Commercial Chassis | 1977-1991 | Shock Absorber | Front | 2 | |
| Cadillac | Commercial Chassis | 1983-1996 | Shock Absorber | Front | RWD | 2 |
| Cadillac | Fleetwood | 1977-1984 | Shock Absorber | Front | 2 | |
| Chevrolet | Corvette | 1963-1982 | Shock Absorber | Front | 2 | |
| Chevrolet | Impala | 1994-1996 | Shock Absorber | Front | 2 |
Product Specifications:
- Extended Length (IN): 14.625
- Extended Length (MM): 371.5
- Lower Mount Type: Cross Pin Mount - Closed Ended, 5/16" Hole ID (Both Ends) X 2.1/2" Pin Length (Hole Center to Center)
- Upper Mount Type: Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch
- Gas Charged: Yes
- Compressed Length (IN): 9.375
- Compressed Length (MM): 238.1
- Travel Length (IN): 5.25
- Travel Length (MM): 133.4
- Shock Absorber Rod End Measuring Point: Base of Stem
- Shock Absorber Body End Measuring Point: Center of Mounting Hole
- Dust Shield Included: Yes
- Dust Shield Material: Metal
- Includes Bump Stop: No
- Upper Mount Code: S4
- Lower Mount Code: XP5
- Hydraulic Lockout: No
- Internal Rebound Bumper: No
- Parts Pack(s) :P01134
